2024 Pursuit OS 405

Pursuit Protection Plan: 5 year Hull & Deck Structural Warranty, 5 year Blister Free Warranty, 2 year Limited Warranty

Pursuit Fresh White Gelcoat

Hand Laminated Hull with Vinyl Ester Resin and Engineered Fabrics

27-Layer Resin Infused Composite Transom System with Patented Transom Reinforcement Grid

Infused Fiberglass Structural Grid System with Molded Finish and Integrated Bilge Water Management System

Foam Filled Structural Grid

Integrated Transom Platform Extensions Outboard of Engines

Integrally Molded Thru-Stern Anchor System with Fresh Water Washdown and Dedicated Hose Storage

Vertical Anchor Windlass with Switch at Helm and Wired handheld Remote Switch at Anchor Locker

35lbs 316L SS Plow Style Anchor, 20' of G-4 Chain, 200' of 5/8" 8 plait Rode and Self-Righting Swivel

316L SS through Stern Anchor Roller with 10" Mooring Cleat, Chain Binder and Aluminum Backing Plates

LED Courtesy Light in Anchor Locker

Bronze Thru Hull Fittings Below Water Line

SS Clad Composite Thru Hull Fittings Above the 7 Degree Heel Line

Chrome over Bronze Thru Hull Fittings below 7 Degree Heel Line

T-Handle Bronze Garboard Drain

4kw HP Bow Thruster with Group 31 AGM Battery with Joystick Control at Helm

5/8" 316L SS Bow Eye

3 Step Telescopic boarding Ladder Mounted in Hull Transom Platform Extension

Tempered Glass Hull Side Windows Port & Starboard

Molded Hull Side Window Mounting Surfaces in Bow with Frameless Tempered Glass Windows

Zipwake Trim Control System, Series S Interceptors, Fully Automatic Pitch and Roll Control

Two (2) 1500 GPH Bilge Pump with High Water Float Switch and Alarm with SS Clad Composite Thru Hull Fittings

Forward Hull Compartmentation with One (1) 1100 GPH Bilge Pump with Automatic Float Switch

Sea keeper 6 Gyroscopic Stabilizer with Integrated Structural Integration, Sea Keeper Factory Certification, Gold Level 4 Year Warranty Package with 3000 hours Operation and Direct Customer Service Included

Molded One Piece Deck and Cockpit Liner with Non-Skid pattern Area and Overboard Drains

Hull and Deck Joint Mechanically Fastened and Thru-Bolted at Cleat Locations

High Density White PVC Rub Rail corners and 316L SS Transom Insert, Molded Rub rail Corners and 316L SS Transom Cap

(8) Total - (2) 10" 316 SS Pop Up Cleats on Stern - 12" 316 SS Cleats (4) on spring and (2) on Bow

Molded Recessed Hatches with Gaskets and 316L SS Latches and Overboard Drain Tracks

316L SS Deck Plates for Water, Waste and Diesel

LED Courtesy Lights with Water Proof Switch in Cockpit

Full Spectrum LED Mid-level Lighting with Control Panel

Custom Tuned JL Audio System: JL Audio Stereo System with 12V Bluetooth Compatible Head Unit, Speakers (7 Total, 4x7.7" Exterior Speakers, 2x 6.5" Exterior Speakers and 10" Subwoofer) and Dual Zone Controls (Bridge 6 Cockpit)

Custom Cockpit Upholstery with Dri-Fast Foam and Mesh Backing

(4) Portlights

Port and Starboard 316L SS Transom Grab Rails

Single Level Splash Well Deck with Non-Skid Pattern Area

316L SS Shore Power Inlet with Electric Cord Retracting Reel and 50' Cord

Dockside Freshwater Inlet with Pressure Regulator

Transom Rod Holders (4)

316L SS Pump Out for Waste

Folding Transom Seat with Full Height Rotating Backrest and Integrated Grab Rails

 Port Lighted Oceana Blue 50 Gallon Recirculating Live well with overboard discharge

Transom Refrigeration Box -75 Gallons (283.91 Liters) Refrigerator/Freezer with Digitally Controlled Thermostat and Fiberglass Lid

Fiberglass Sink with Hot / Cold faucet

Cutting Board

Port and Starboard Molded Aft Facing Cockpit Seats with Tub Storage Below

Custom Cockpit Upholstery with Dri-Fast Foam and Mesh Backing

4) Portlights

Port and Starboard 316L Stainless Steel Transom Grab Rails

Single Level Splash Well Deck with Non-Skid Pattern Area

316L Stainless Steel Shore Power Inlet with Electric Cord Retracting Reel and 50' Cord

Dockside Freshwater Inlet with Pressure Regulator

Transom Rod Holders (4)

316L Stainless Steel Pump out for Waste

Folding Transom Seat with Full Height Rotating Backrest and Integrated Grab Rails

Port Lighted Oceana Blue 50 Gallon Recirculating Live well with overboard discharge

Transom Refrigeration Box -75 Gallons (283.91 Liters) Refrigerator/Freezer with Digitally Controlled Thermostat and Fiberglass Lid

Fiberglass Sink with Hot / Cold faucet

Cutting Board

Port and Starboard Molded Aft Facing Cockpit Seats with Tub Storage Below

Custom Cockpit Upholstery with Dri-Fast Foam and Mesh Backing

Full Cockpit Breathable Coaming Bolsters with High Density Foam

Custom Molded Cockpit Table with Dedicated Storage Location

316L Stainless Steel Cockpit Extra Deep Drink Holders (4)

Custom Molded Side Boarding Door (Port) with Heavy Duty 316L Stainless Steel Hardware and Deck Mounted 316L Stainless Steel Keyway Plate for Dive Style Telescoping Ladder

Lighted Oceana Blue 50 Gallon Recirculating Live well, Fiberglass Lid with Acrylic Window

Port Cockpit Tackle Center with Storage for Four (4) Plano® Boxes and a Tackle Drawer

Starboard - 39 Gallons (147.63 Liters) Fish box in Cockpit Floor with Molded Foam Insulation and Dedicated Diaphragm Discharge Pump

Port - 50 Gallons (189.27 Liters) Fish box in Cockpit Floor with Molded Foam Insulation and Dedicated Diaphragm Discharge Pump

Transom Refrigeration Box -75 Gallons (283.91 Liters) Refrigerator/Freezer with Digitally Controlled Thermostat and Fiberglass Lid

Four 316L Stainless Steel Rod Holders in Gunwales

Aluminum Reinforcement Plates and Wiring for Downrigger Installation, Port and Starboard

Molded Cockpit Entertainment Center with Electric Grill, Fiberglass Lid

Tackle Center with Drawers

Aft Cockpit Machinery Access Hatch

Aft Facing Seat / Machinery Access Hatch

Fresh Water Wash with Hot / Cold Mixing Valve and Pull out Sprayer STBD. Aft Cockpit

Outboard Engine Flush with Diverter Valve in Aft Cockpit

Raw Water Outlet Port Aft Cockpit with Quick Connect Fittings and 25' Coil Hose

316L Stainless Steel Deck Plates for Water, Waste and Diesel

Self-Draining Cockpit with Molded Water Management System, with (2) Drain and 316L Stainless Steel Drainage Grate

12 lb. Galvanized Stern Anchor with 30' 1/2" 8 Plait Rode and Dedicated Storage in the Machinery Space

LED Machinery Space Lights (2) Forward and Aft

360° Swivel Captain's Helm Seat with (Up / Down & Fore / Aft Adjustments) Folding Arm Rests, Custom Upholstery

Companion Seat with Adjustable Backrest with Fore and Aft Facing Positions

240V/60 Cycle Cockpit Air Conditioning with Reverse Cycle Heat. Port & Starboard 10,000 BTU Self Contained Units with Bronze Sea Strainers, Seacocks and Thru Hull Fittings; Stamoid/Macrolon Side and Drop Curtains

Center Bridge Storage Hatch / Fuel Access Hatch

Starboard Refrigerator/ Freezer Tub

Teak Table that Converts into Berth

Storage Drawer under Companion Seat

Cupholders: Two (2) Starboard and Three (3) Lounge

DC MDP Panel

Flush Mounted Integral Anchor Locker with Fiberglass Lid and Gas Shock

One-Piece Welded 316L Stainless Steel Fore Deck Rail

Two-Piece Welded 316L Stainless Steel Grab Rails for Sun Pad

Bow Sun Pad Chaise Style Seating with Adjustable Backrests with Stamoid Cover

Quick Disconnects for Fresh & Raw Wash Downs and a Courtesy Light inside Anchor Locker

Flush Bow Hatch with screen

• Molded Fiberglass Full Beam Hardtop with Visor
• White Powder Coated Hardtop Supports with 2 Rod Holders Per Side
• Custom Windshield System with Optically Clear Laminated Windshield Glass with Electrically Actuated Vent Window, Tempered Side Glass with Infused Fiberglass Frame
• Anchor/Stern LED Navigation Lights with Burgee/Flag Mounts and Embroidered American Flag
• FM Antenna
• Six (6) Tri Color LED Lights
• Two (2) Aft Facing Spreader Lights
• Powder Coated Trumpet Air Horn with 316L Stainless Steel Mount
• 316L Stainless Steel Aft Grabrails Port and Starboard
• 316L Stainless Steel Underside Center Grabrail
• 2 - Sliding Bomar Hatches with Shades
• Port & Starboard Gloveboxes
• Two (2) JL® 7.7 Exterior Speakers and Two (2) JL® 6.5 Speakers

• Molded Fiberglass Helm with Instrumentation Visor, Electronics Mounting Surface
• Fold Down Platform Step with Non Skid for Secondary Standing Operating Position
• Electronics Mounting Face that Accommodates 22" Screens
• Garmin® GPSMAP 8622xsv 22" Multi-touch Widescreen Display
• Garmin® GPSMAP 8622mfd 22" Multi-touch Widescreen Display
• Garmin® VHF 315 Marine Radio In Coaming
• Yamaha Electronic Steering Control with Programable Steering Friction
• Edson 316L Stainless Steel Steering Wheel with Textured Grip and Control Knob
• JL Media Master Head Unit with Auxiliary Input Port
• Single Windshield Wiper Washer Control
• Ritchie® Navigator Compass
• 12V Switch Panel with Back Light Function Display and Custom Accents
• Bow Thruster Control
• One (1) Drink holder
• Dual USB Charger (1)
• 12V Outlet at Helm
• Garmin® Micro SD Card Reader

• Molded Acrylic Access Door with Secondary Framed Screen Door and 316L Stainless Steel Locking Latch
• Full Fiberglass Hull Liner with Sound Damping Insulation
• Cabin Entry Steps with Wood Treads
• Custom Solid Wood Tongue and Groove Floor
• Solid Wood Veneers on Interior Cabinetry with Corian Accents / Tops
• Hanging Locker
• Electrically Convertible Island-style Berth: Queen Size Memory Foam Mattress with Hinging Backrests, Gas-assisted Mattress Base with Underneath Storage
• Port & Starboard 120v Outlets, 12v plugs and USB Chargers
• Port & Starboard Tempered Glass Hull Side Windows with Custom Window Trim with Marine Grade Pleated Blinds
• CO Monitor
• AC Distribution Panel
• Fire Extinguisher
• Main Cabin Switch Panel: (4) Accent Floor Lights, (6) Overhead LED at Berth, (3) Indirect Strip Lighting
• Two Reading Lights are Individually Switched
• 240V/60 Cycle Cabin Air Conditioning with Reverse Cycle Heat. 16,000 BTU Self Contained Unit with Bronze Sea Strainer, Seacock and Thru Hull Fitting
• Four (4) Portlight Windows
• Sofa with Storage Beneath
• Vitero Two Drawer Refrigerator
• 1.1 ft3 120V Microwave Oven
• Two Burner Cooktop
• Integrated Storage with (2) Drawers
• Sink / Cutting Board
• Pull Out Trash Can
• 32" Smart TV
• Integrated AC Ducts

• Fiberglass Private Head Compartment with Non-Skid Pattern Area
• Solid Surface Countertop with Sink and Storage Cabinet Below
• Tempered Glass Hull Side Window with Custom Window Trim with Marine Grade Pleated Blind
• Portlight Window
• Vacu-Flush Porcelain Elongated Bowl Marine Head with 22 Gallon Holding Tank, Macerator Discharge Pump, 316L Stainless Steel Deck Pump-out Fitting and Bronze Through Hull Fitting
• FRP Head Seat Cover
• Linen Closet with Shower Door
• Upper Vanity Storage Cabinet
• Head Mirror
• Head Door with Two Towel Hooks
• Toilet Tissue Holder
• Towel Rack
• Two Switch Panel with Two (2) Overhead LED Light, (1) LED Floor Accent Light
• Shower Sump Box Drain with Automatic Discharge
• Shower with Hot/Cold Mixing Valve, Shower Wand
• Shower Curtain
• 120V Outlet with GFI Protection (1)

• AC MDP Cabinet
• Battery Charger Cabinet
• Dedicated Seat
• Full Size Bed
• Rod Storage: Three (3)
• Two Switch Panel: Three (3) Overhead Lights and Two (2) Courtesy Lights
• FWD Mechanical Access Hatch
• Water Manifold Hatch

• UL® Rated Fully Tinned, Color Coded Copper Wire
• Custom Built, Heat Sealed, Mechanically Crimped, Color Coded Battery Cables
• Custom Built, One Piece Electrical Harness with Water Proof Connectors and Chafe Protection
• Powder Coated, Aluminum, Screen Printed (Front & Back) Main Breaker Panels
• Bonding System: Thru Hull Fittings Below Water Line, Zinc Anode and T-Handle Drain
• 240V 50 Amp 60 Cycle Dockside Power Connection
• Electrically Retractable Shore Power Cord Reel with 50' Cord
• Nine 120V Outlets with GFI Protection (9)
• One 40 AMP Battery Charger For House, Electronics, and Bow Thruster Bank
• One 25 AMP Battery Charger for Engine Bank
• Isolation Transformer
• 12V Outlets (2) and Four Dual USB Chargers (4)
• Seven (7) Battery System: Port Engine (1) Center Engine (1) Starboard Engine (1), House (AGM) (2), Electronics (AGM) (1), Bow Thruster (1) (AGM)
• One Grounding Bus Bar

• Fisher Panda 9kw 120/240V, 60hz Diesel Generator with Sound Enclosure and Service Slide
• EPA Compliant Lined 31 Gallon Diesel Fuel Tank with Engine Pickups, Shutoff Valves and Digital Level Indicator
• Automatic Fire Suppression System

• Molded Interior White Gel Coat Structural Foundation
• Molded Hatch with Gasket and Stainless Steel Gas Spring
• Molded Bilge Sump Area
• Two (2) 1500 GPH Bilge Pump with High Water Float Switch and Alarm with Stainless Steel Clad Composite Thru Hull Fittings
• Bilge High Water Alarm
• Live well Cyclone Pump with Bronze Sea Strainer, Seacock and Thru Hull Fitting
• SeaKeeper Pump with Bronze Sea Strainer, Seacock and Thru Hull Fitting
• Raw Water Pump with Bronze Sea Strainer, Seacock and Thru Hull Fitting
• Dedicated Storage for 12lb Stern Anchor
• Dedicated Storage for Boarding Ladder (Ladder to be shared between Dive Door and Platform)
• 316L Stainless Steel Battery Service Slide System Port and Starboard
• Access Step

• EPA Compliant 510 Gallon Aluminum Fuel Tank with Engine Pickups (3), Shutoff Valves (3) and Digital Level Indicator (1)
• Custom Built Fuel Lines with Mechanically Crimped Fittings
• Three Yamaha® Water Separating Fuel Filters with Primer Bulbs

• 80 Gallon Water Tank with Level Indicator
• Custom Built Reinforced Color Coded Water Hose
• Fresh Water Pressure Sensing Pump with Filter
• Dockside Fresh Water Inlet with Pressure Regulator
• 6 Gallon Stainless Steel Hot Water Heater 240V 60 Cycle
• 18 Circuit Water Distribution Manifold with Dedicated Valves
