Pursuit C 238 Center Console - main image

2017 Pursuit C 238 Center Console

location icon Lopez Island, Washington
Year 2017
Length 23 ft

Pursuit takes their entry level center console to new heights.  The all new C238 comes standard with a fiberglass hardtop, a walk-in console with head and a tempered glass windshield for great protection and excellent visibility. Perfect for cruising around the islands.

Specifications

Year Built 2017
Category Power
Length Overall 23 ft
Construction Fiberglass
Hull ID SSUC2656L617
Engines 1
Total Engine Power 300 hp

Engine 1 Specifications

Make: Yamaha
Model: F300 W/C LINK
Fuel: Unleaded
Engine Power: 300hp
Type: Outboard 4 Stroke
Year: 2017
FACTORY FEATURES

Tilt Helm

Upgrade to hard rubrail w/SS insert

Windlass/anchoring system

Upgrade SS Delta anchor

Stereo, AM/FM/USB Bluetooth w/4 speakers

STANDARD EQUIPMENT

Pursuit Protection Plan: 5-year hull/deck structural warranty, 5-year blister-free warranty 2-year limited warranty

Basic floatation

Pursuit Fresh White gelcoat

Hand laminated hull with Vinyl Ester resin and engineered fabrics

Infused fiberglass structural grid system with molded finish and integrated bilge water management system

5 ply resin infused composite transom system

Integrated Transom Platform Extensions outboard of engines

Trim tabs with indicator lights and auto-retract

Self-draining rope and anchor locker

Bronze thru hull fittings below water line

Chrome over bronze thru hull fittings below 7 degree heel line

SS clad composite thru hull fittings above the 7 degree heel line

Bronze garboard drain

3 step telescopic boarding ladder mounted in hull platform

Electric oval horn w/SS cover

High density PVC soft rubrail

1/2" 316L SS bow eye

1/2" 316 SS stern eyes (2)

Molded one piece deck & cockpit liner with non-skid pattern area and overboard drains

Hull and deck joint mechanically fastened

8" 316L SS pop up cleats (2) stern, (2) mid-ship and (2) on bow

Molded recessed hatches with gaskets and 316 SS latches and overboard drain tracks

Flush mounted integral anchor locker with fiberglass lid

Two SS grab rails in bow (port & stbd)

Four 315L SS rod holders in gunwales

Under gunwale rod storage, port and stbd

Molded transom  walkthrough and hinged HDPE transom door with 316L SS latch and positive catch

Port 316L SS transom grab rails

Custom cockpit upholstery with Dri-Fast foam and mesh backing

FRP leaning post/powder coated frame with dedicated cooler space

Lighted Oceana Blue 23 gallon recirculating live well

Folding stern seat

Forward bow seating cushions, with folding backrest and bolsters

316L SS cockpit drink holders (2) bow, and (2) in gunwales

Bow seating port and starboard with fiberglass hatches and storage below

Raw water outlet in cockpit with quick connect fittings and 25' hose

LED cockpit accent lights (4)

Port and stbd 2 mile LED navigation lights

316L SS deck plates for water and waste

Anchor roller chute/ 8" cleat with chain binder











CONSOLE AND HELM

Molded console with fixed helm, integrated footrest and forward facing seat

Hydraulic steering pump

13.5" 316L SS steering wheel

12V switch panel

316L SS helm drink holders (2)

Compass

Trim tab control panel and indicator

316L SS grab rail

One 12V outlet and dual USB charger -1

Helm fire extinguisher

Tempered glass windscreen with powder coated frame

Sanipottie head with pumpout

HARDTOP

Molded fiberglass hardtop

Overhead glove box

Powder coated structural hardtop support

4 rod holders

Combination anchor/stern LED all-around navigation light

White lights

Aft facing LED spreader light

ELECTRICAL SYSTEMS

UL rated fully tinned, color coded copper wire

Custom built, heat sealed, mechanically crimped, color coded battery cables

Custom built, one piece electrical harness with water proof connectors and chafe protection

Powder coated, aluminum, screen printed (front and back) battery switch and breaker panel

Two battery systems: engine (1) and house (1)

One grounding bus bar

Electronics fuse block

MECHANICAL SYSTEMS

Molded interior white gel coat

Removable access hatch

Molded bilge sump area

900 GPH low profile bilge pump with automatic float switch and SS clad composite thru hull fittings

1100 GPH tournament series live well pump, sea cock and thru hull fitting

Pressure sensing raw water pump with in-line filter



FUEL SYSTEMS

EPA compliant lined 105 gallon rotomolded fuel tank with engine pickup, shutoff valve and digital level indicator

Custom built fuel lines with mechanically crimped fittings

Yamaha water separating fuel filter with primer bulb

President
The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
